9.5 Cover plate drawing
The cover plate is not included in the ABB Turbo Systems scope of delivery and must be
manufactured by the operating company according to the following drawing.
Material: General structural steel, in compliance with DIN EN 10025-2.
Figure 56: Cover plate drawing
Product
B1
± 0.5
B2
B3
B4
± 0.2
B5
B6
B7
ØD1
± 0.2
ØD2
R1
M
A130
65.7
60
130
11.7
1.4
150
35.7
227.7
17
≤ 105
M8
A135 79.6 80 155 14.2 1.6 180 39.6 271.7 21 ≤ 125 M8
A140
98.2
102
190
17.2
2.0
220
48.2
332.5
25
≤ 153
M10
Table 47: Cover plate dimensions [mm]
