G1 Introduction to AC500 1-6 AC500 / Issued: 07.2006
Overview of available CPU terminal bases
Type Order number Description
TB511-
ARCNET
1SAP111 100 R0160 TB511-ARCNET, CPU Terminal Base AC500, 1x CPU
Slot, 1x Coupler Slot, ARCNET COAX Connector
TB511-ETH
1SAP 111 100 R0170 TB511-ETH, CPU Terminal Base AC500, 1x CPU Slot, 1x
Coupler Slot, Ethernet RJ45 Connector
TB521-
ARCNET
1SAP 112 100 R0160 TB521-ARCNET, Terminal Base AC500, 1x CPU Slot, 2x
Coupler Slots, ARCNET COAX Connector
TB521-ETH
1SAP 112 100 R0170 TB521-ETH, CPU Terminal Base AC500, 1x CPU Slot, 2x
Coupler Slots, Ethernet RJ45 Connector
TB541-ETH
1SAP 114 100 R0170 TB541-ETH, CPU Terminal Base AC500, 1x CPU Slot, 4x
Coupler Slots, Ethernet RJ45 Connector
Overview of available I/O modules
Type Order Number Description
DI524
1SAP 240 000 R0001 DI524, Digital Input Module, 32 DI, 24 V DC, 1-wire
DC522
1SAP 240 600 R0001 DC522, Digital input/output module, 16 DC, 24 V DC / 0.5
A, 2-wire
DC523
1SAP 240 500 R0001 DC523, Digital input/output module, 24 DC, 24 V DC / 0.5
A, 1-wire
DC532
1SAP 240 100 R0001 DC532, Digital Input/Output Module, 16 DI / 16 DC, 24 V
DC / 0.5 A, 1-wire
DX522
1SAP 245 200 R0001 DX522, Digital Input/Output Module, 8 DI 24 V DC, 8 DO
Relay, 2-wire
DX531
1SAP 245 000 R0001 DX531, Digital Input/Output Module, 8 DI, 230 V AC, 4 DO
Relay, 2-wire
AI523
1SAP 250 300 R0001 AI523, Analog input module, 16 AI, U/I/Pt100, 12 Bit + sign,
2-wires
AO523
1SAP 250 200 R0001 AO523, Analog output module, 16 AO, U/I, 12 Bit + sign, 2-
wires
AX521
1SAP 250 100 R0001 AX521, Analog input/output module, 4 AI / 4 AO, U/I/Pt100,
12 Bit + sign, 2-wires
AX522
1SAP 250 000 R0001 AX522, Analog Input/Output Module, 8 AI / 8 AO,
U/I/Pt100, 12 Bit + sign, 2-wire
Overview of available terminal units
Type Order Number Description
TU515
1SAP 212 200 R0001 TU515, I/O Terminal Unit, 24 V DC, Screw Terminals
TU516
1SAP 212 000 R0001 TU516, I/O Terminal Unit, 24 V DC, Spring Terminals
TU531
1SAP 217 200 R0001 TU531, I/O Terminal Unit, 230 V AC, Relay, Screw
Terminals
TU532
1SAP 217 000 R0001 TU532, I/O Terminal Unit, 230 V AC, Relay, Spring
Terminals
TU551-CS31
1SAP 210 600 R0001 TU551-CS31, Bus-I/O Terminal Unit, 24 V DC, Screw
Terminals
TU552-CS31
1SAP 210 400 R0001 TU552-CS31, Bus-I/O Terminal Unit, 24 V DC, Spring
Terminals
