Maintenance
111
LEDs
This table describes LEDs of the drive.
Where LED When the LED is lit
RMIO board Red Drive in fault state
Green The power supply on the board is OK.
Control panel mounting platform Red Drive in fault state
Green The main + 24 V power supply for the control panel and the
RMIO board is OK.
AINT board V204 (green) +5 V voltage of the board is OK.
V309 (red) Prevention of unexpected start-up (option +Q950) or Safe
torque off (option +Q968) is ON.
V310 (green) IGBT control signal transmission to the gate driver control
boards is enabled.
