ABB ACS800-U7 - Cable Entries; Dimensions, Weights and Noise

Technical data
127
Cable entries
Input, motor and brake resistor cable terminal sizes (per phase) and tightening
torques are given below. Two-hole 1/2 inch diameter cable lugs can be used.
Dimensions, weights and noise
1)
in marine applications (+C121) extra height: 0.39 in. from the fastening bar at the bottom of the
cabinet
2)
extra width for units with brake resistors (+D151): SAFURxxxFxxx 15.75 in., 2xSAFURxxxFxxx
19.68 in., 4xSAFURxxxFxxx 62.99 in.
3)
extra width for units with EMC filter (+E202): 7.87 in.
4)
extra width for units with EMC filter (+E202): 15.75 in.
5)
in marine applications (+C121) depth with fastening bars: 27.56 in.
Frame
size
L1, L2, L3, U2, V2, W2, UDC+/R+, UDC-, R- Earthing PE
Max. cable Screw Tightening torque Screw Tightening torque
kcmil/AWG lbf ft lbf ft
R6 350 MCM 3/8 14.8...29.5 3/8 22...32
R7 2 × 250 MCM 1/2 37...55 3/8 22...32
R8 3 × 700 MCM 1/2 37...55 3/8 22...32
Frame size Height
1)
Width
2)
Depth
5)
Weight Noise
UL type 1 UL type 12
in. in. in. in. lb dB
R6 84.22 91.08 16.93 27.28 700 63
R7 84.22 91.08 32.92
3)
27.28 900 71
R8 84.22 91.08 32.92
4)
27.28 1100 72
