ABB ACS800-U7 - Page 114

Technical data
114
1)
50% overload is available for one minute every 5 minutes if ambient temperature is less than 25 °C
(77 °F). If ambient temperature is 40 °C (104 °F), max. available overload is 37%.
2)
50% overload is available for one minute every 5 minutes if ambient temperature is less than 30 °C
(86 °F). If ambient temperature is 40 °C (104 °F), max. available overload is 40%.
3)
50% overload is available one minute every 5 minutes if ambient temperature is less than 20 °C
(68 °F). If ambient temperature is 40 °C (104 °F), max. available overload is 30%.
4)
Higher value is valid if ambient temperature is less than 35 °C (95 °F).
*
Higher value applicable if output frequency is above 41 Hz
**
MANUFACTURED ON SPECIAL ORDER ONLY
Three-phase supply voltage 380 V, 400 V, 415 V, 440 V, 460 V, 480 V or 500 V
-0105-5 145 170 90 141 90 100 55 R5 405 2150
-0120-5 157 202 90 145 90 113 75 R6 405 2310
-0140-5 180 282 110 163 110 141 90 R6 405 2810
-0165-5 225 326 132 220 132 163 110 R6 405 3260
-0205-5 260 326 160 254 160 215 132 R6 405 3800
-0255-5 290 351 200 285 200 234 160 R6 405 4500
-0320-5 440 588 250 435 250 340 200 R8 1220 6850
-0400-5 515 588 315 510 315 370 250 R8 1220 7800
-0440-5 550 840 355 545 355 490 315 R8 1220 7600
-0490-5 602 840 400 590 400 515
2)
355 R8 1220 8100
-0550-5 684 1017 450 670 450 590
2)
400 R8 1220 9100
-0610-5 718 1017 500 704 500 632
3)
450 R8 1220 9700
Three-phase supply voltage 525 V, 550 V, 575 V, 600 V, 660 V or 690 V
-0070-7 79 104 75 73 55 54 45 R6 405 1220
-0100-7 93 124 90 86 75 62 55 R6 405 1650
-0120-7 113 172 110 108 90 86 75 R6 405 1960
-0145-7 134 190 132 125 110 95 90 R6 405 2660
-0175-7 166 245 160 155 132 131 110 R6 405 3470
-0205-7 190 245 160 180 160 147 132 R6 405 4180
-0260-7 175/230* 326 160/200* 175/212* 160/200* 163 160 R7 540 4800
-0320-7 315 433 315 290 250 216 200 R8 1220 6150
-0400-7 353 548 355 344 315 274 250 R8 1220 6650
-0440-7 396 656 400 387 355 328 315 R8 1220 7400
-0490-7 445 775 450 426 400 387 355 R8 1220 8450
-0550-7 488 853 500 482 450 426 400 R8 1220 8300
-0610-7 560 964 560 537 500 482 450 R8 1220 9750
00096931
ACS800-07 type Nominal ratings No-
overload
use
Light-overload use Heavy-duty use Frame
size
Air flow Heat
dissipation
I
cont.max
A
I
max
A
P
cont.max
kW
I
2N
A
P
N
kW
I
2hd
A
P
hd
kW m
3
/h W
