Resistor braking
143
690 V units
-0070-7 R6 ---45SAFUR90F575 8.0018004.5
-0100-7 R6 ---55SAFUR80F500 6.0024006
-0120-7 R6 ---75SAFUR80F500 6.0024006
-0145-7 R6 ---160SAFUR80F500 6.0024006
-0175-7 R6 ---160SAFUR80F500 6.0024006
-0205-7R6---160SAFUR80F500 6.0024006
-0260-7 R7 135
5)
120 100 80 SAFUR80F500 6.00 2400 6
-0320-7 R8 300 300 300 260 SAFUR200F500 2.70 5400 13.5
-0400-7 R8 375 375 375 375 SAFUR200F500 2.70 5400 13.5
-0440-7 R8 430 430 430 385 SAFUR200F500 2.70 5400 13.5
-0490-7 R8 550 400 315 225 2xSAFUR125F500 2.00 7200 18
-0550-7 R8 550 400 315 225 2xSAFUR125F500 2.00 7200 18
-0610-7 R8 550 400 315 225 2xSAFUR125F500 2.00 7200 18
00096931-J
P
br5
Maximum braking power of the drive with the specified resistor(s). The drive and the chopper will withstand this
braking power for 5 seconds per minute.
P
br10
The drive and the chopper will withstand this braking power for 10 seconds per minute.
P
br30
The drive and the chopper will withstand this braking power for 30 seconds per minute.
P
brcon
t
The drive and the chopper will withstand this continuous braking power. The braking is considered continuous if the
braking time exceeds 30 s.
Note: Check that the braking energy transmitted to the specified resistor(s) in 400 seconds does not exceed E
R
.
R Resistance value for the resistor assembly. Note: This is also the minimum allowed resistance for the brake
resistor.
E
R
Short energy pulse that the resistor assembly withstands every 400 seconds. This energy will heat the resistor
element from 40 °C (104 °F) to the maximum allowable temperature.
P
Rcont
Continuous power (heat) dissipation of the resistor when placed correctly. Energy E
R
dissipates in 400 seconds.
* ACS800-0x types only
** ACS800-Ux types only
1) 240 kW possible if ambient temperature is below 33 °C (91 °F)
2) 160 kW possible if ambient temperature is below 33 °C (91 °F)
3) 630 kW possible if ambient temperature is below 33 °C (91 °F)
4) 450 kW possible if ambient temperature is below 33 °C (91 °F)
5) 160 kW possible if ambient temperature is below 33 °C (91 °F)
ACS800-07/U7
type
Frame
size
Braking power of the chopper and
the drive
Brake resistor(s)
5/60 s
P
br5
(kW)
10/60 s
P
br10
(kW)
30/60 s
P
br30
(kW)
P
brcont
(kW)
Type R
(ohm)
E
R
(kJ)
P
Rcont
(kW)
