Operation principle and hardware description
24
Cabinet options +G300 cabinet heater (external supply)
+G304 115 VAC control voltage
+G307 terminals for external control voltage (UPS)
+G313 output for motor heater (external supply)
+G330 halogen-free materials and control wiring
+G338 wire marking class A1
+G339 wire marking class A2
+G340 wire marking class A3
+G341 wire marking class B1
+G342 wire marking class C1
Cabling +H351 top entry
+H353 top exit
+H350 bottom entry
+H352 bottom exit
+H356 DC cable connection busbars
+H358 cable conduit entry (US and UK version)
Fieldbus +Kxxx Refer to ACS800 Ordering Information (EN code: 64556568).
I/O +L504 additional terminal block X2
+L505 thermistor relay (1 or 2 pcs)
+L506 Pt100 relay (3, 5 or 8 pcs)
+Lxxx Refer to ACS800 Ordering Information (EN code: 64556568).
Starter for auxiliary
motor fan
+M600 1...1.6 A
+M601 1.6...2.5 A
+M602 2.5...4 A
+M603 4...6.3 A
+M604 6.3...10 A
+M605 10...16 A
Control program +Nxxx Refer to ACS800 Ordering Information (EN code: 64556568).
Language of manual +Rxxx
Specialities +P901 coated boards
+P902 customized
+P904 extended warranty
+P913 special colour
+P912 seaworthy packing
+P929 container packing
Safety features +Q950 Prevention of unexpected start-up
+Q951 Emergency stop of category 0 with opening the main contactor/
breaker (+F250 required)
+Q952 Emergency stop of category 1 with opening the main contactor/
breaker (+F250 required)
+Q963 Emergency Stop, Category 0 without opening the main contactor/
breaker
+Q964 Emergency Stop, Category 1 without opening the main contactor/
breaker (SS1)
+Q968 Safe torque off STO with a safety relay
+Q954 Earth fault monitoring for IT (ungrounded) systems
+Q971 ATEX certified safety functions
