148 Parameters
KTY 2nd FEN The temperature is supervised using a KTY84 sensor
connected to encoder interface module FEN-xx installed in
drive Slot 1/2. If two encoder interface modules are used,
encoder module connected to Slot 2 is used for the
temperature supervision.
Note: This selection does not apply to FEN-01.
3
PTC JCU The temperature is supervised using 1…3 PTC sensors
connected to drive thermistor input TH.
4
PTC 1st FEN The temperature is supervised using a PTC sensor
connected to encoder interface module FEN-xx installed in
drive Slot 1/2. If two encoder interface modules are used,
encoder module connected to Slot 1 is used for the
temperature supervision.
5
PTC 2nd FEN The temperature is supervised using a PTC sensor
connected to encoder interface module FEN-xx installed in
drive Slot 1/2. If two encoder interface modules are used,
encoder module connected to Slot 2 is used for the
temperature supervision.
6
Pt100 JCU x1 The temperature is supervised using a Pt100 sensor
connected to analog input AI1 and analog output AO1 on the
JCU Control Unit of the drive.
7
Pt100 JCU x2 The temperature is supervised using two Pt100 sensors
connected to analog input AI1 and analog output AO1 on the
JCU Control Unit of the drive.
8
Pt100 JCU x3 The temperature is supervised using three Pt100 sensors
connected to analog input AI1 and analog output AI1 on the
JCU Control Unit of the drive.
9
Pt100 Ext x1 The temperature is supervised using a Pt100 sensor
connected to the first available analog input and analog
output on I/O extensions installed on the drive.
10
Pt100 Ext x2 The temperature is supervised using two Pt100 sensors
connected to the first available analog input and analog
output on I/O extensions installed on the drive.
11
Pt100 Ext x3 The temperature is supervised using three Pt100 sensors
connected to the first available analog input and analog
output on I/O extensions installed on the drive.
12
31.07 Mot temp2 almLim Defines the alarm limit for the motor thermal protection 2
(when parameter 31.05 Mot temp2 prot is set to either Alarm
or Fault).
0 … 200 °C Motor overtemperature alarm limit. 1 = 1 °C
31.08 Mot temp2 fltLim Defines the fault limit for the motor thermal protection 2 (when
parameter 31.05 Mot temp2 prot is set to Fault).
0 … 200 °C Motor overtemperature fault limit. 1 = 1 °C
31.09 Mot ambient temp Defines the ambient temperature for the thermal protection
mode.
-60 … 100 °C Ambient temperature. 1 = 1 °C
No. Name/Value Description FbEq
