ABB ACS850 - User Motor Par

198 Parameters
97
97 User motor par
Motor values supplied by the user that are used in the motor
model.
97.01 Use given params Activates the motor model parameters 97.02…97.14.
Notes:
Parameter value is automatically set to zero when ID run is
selected by parameter 99.13 Idrun mode. The values of
parameters 97.02…97.14 are updated according to the motor
characteristics identified during the ID run.
This parameter cannot be changed while the drive is running.
0 Parameters 97.02…97.14 inactive. 0
1 The values of parameters 97.02…97.14 are used in the motor
model.
1
97.02 Rs user Defines the stator resistance R
S
of the motor model.
0.00000 … 0.50000
p.u.
Stator resistance in per unit. 100000 =
1p.u.
97.03 Rr user Defines the rotor resistance R
R
of the motor model.
Note: This parameter is valid only for asynchronous motors.
0.00000 … 0.50000
p.u.
Rotor resistance in per unit. 100000 =
1p.u.
97.04 Lm user Defines the main inductance L
M
of the motor model.
Note: This parameter is valid only for asynchronous motors.
0.00000 …
10.00000 p.u.
Main inductance in per unit. 100000 =
1p.u.
97.05 SigmaL user Defines the leakage inductance
σL
S
.
Note: This parameter is valid only for asynchronous motors.
0.00000 … 1.00000
p.u.
Leakage inductance in per unit. 100000 =
1p.u.
97.06 Ld user Defines the direct axis (synchronous) inductance.
Note: This parameter is valid only for permanent magnet
motors.
0.00000 …
10.00000 p.u
Direct axis inductance in per unit. 100000 =
1p.u.
97.07 Lq user Defines the quadrature axis (synchronous) inductance.
Note: This parameter is valid only for permanent magnet
motors.
0.00000 …
10.00000 p.u
Quadrature axis inductance in per unit. 100000 =
1p.u.
97.08 Pm flux user Defines the permanent magnet flux.
Note: This parameter is valid only for permanent magnet
motors.
0.00000 … 2.00000
p.u
Permanent magnet flux in per unit. 100000 =
1p.u.
97.09 Rs user SI Defines the stator resistance R
S
of the motor model.
0.00000 …
100.00000 ohm
Stator resistance. 100000 =
1ohm
97.10 Rr user SI Defines the rotor resistance R
R
of the motor model.
Note: This parameter is valid only for asynchronous motors.
0.00000 …
100.00000 ohm
Rotor resistance. 100000 =
1ohm
No. Name/Value Description FbEq
