Parameters 153
SpRef ramped 03.05 SpeedRef ramped (see page 71). 1073742597
SpRef used 03.06 SpeedRef used (see page 71). 1073742598
TorqRef used 03.14 Torq ref used (see page 71). 1073742606
Process act 04.03 Process act (see page 72). 1073742851
Proc PID out 04.05 Process PID out (see page 72). 1073742853
Pointer Value pointer setting (see Terms and abbreviations on page
63).
-
33.07 Superv2 hi Selects the upper limit for supervision 2. See parameter 33.05
Superv2 func.
-32768.00 …
32768.00
Upper limit for supervision 2. 100 = 1
33.08 Superv2 lo Selects the lower limit for supervision 2. See parameter 33.05
Superv2 func.
-32768.00 …
32768.00
Lower limit for supervision 2. 100 = 1
33.09 Superv3 func Selects the mode of supervision 3.
Disabled Supervision 3 not in use. 0
Low When the signal selected by parameter 33.10 Superv3 act
falls below the value of parameter 33.12 Superv3 lo, bit 2 of
06.13 Superv status is activated.
1
High When the signal selected by parameter 33.10 Superv2 act
exceeds the value of parameter 33.11 Superv3 hi, bit 2 of
06.13 Superv status is activated.
2
Abs Low When the absolute value of the signal selected by parameter
33.10 Superv3 act falls below the value of parameter 33.12
Superv3 lo, bit 2 of 06.13 Superv status
is activated.
3
Abs High When the absolute value of the signal selected by parameter
33.10 Superv2 act exceeds the value of parameter 33.11
Superv3 hi, bit 2 of 06.13 Superv status is activated.
4
33.10 Superv3 act Selects the signal to be monitored by supervision 3. See
parameter 33.09 Superv3 func.
Speed rpm 01.01 Motor speed rpm (see page 64). 1073742081
Speed % 01.02 Motor speed % (see page 64). 1073742082
Frequency 01.03 Output frequency (see page 64). 1073742083
Current 01.04 Motor current (see page 64). 1073742084
Current % 01.05 Motor current % (see page 64). 1073742085
Torque 01.06 Motor torque (see page 64). 1073742086
Dc-voltage 01.07 Dc-voltage (see page 64). 1073742087
Power inu 01.22 Power inu out (see page 64). 1073742102
Power motor 01.23 Motor power (see page 64). 1073742103
SpRef unramp 03.03 SpeedRef unramp (see page 71). 1073742595
SpRef ramped 03.05 SpeedRef ramped (see page 71). 1073742597
SpRef used 03.06
SpeedRef used (see page 71). 1073742598
TorqRef used 03.14 Torq ref used (see page 71). 1073742606
Process act 04.03 Process act (see page 72). 1073742851
Proc PID out 04.05 Process PID out (see page 72). 1073742853
No. Name/Value Description FbEq
