ABB Advant Controller 450 Product Guide

Advant Controller 450 Product Guide
3BSE 015 953R201 Rev B 8-23
8.6.12 S100 I/O System
Table 8-41. S100 I/O Subracks for RM500 Cabinets
Description Consists of Article No.
Subrack with single 5V regulator DSRF 197
DSSR 122
3BSE019999R1
Subrack with redundant 5V regulator DSRF 200
(1)
3xDSSR 170
(1)Voting unit DSSS 171 has to be used if redundant 24V (24VA and 24VB) will be connected to the subrack.
3BSE020178R1
Voting unit for voting of 24V A or B when
redundancy
DSSS 171 3BSE005003R1
Table 8-42. Cables for S100 I/O bus extension
Description Consists of Article No.
Connection kit for single S100 I/O bus
extension to I/O subrack
For subrack no. 1
TK575: 2.5 m (8.3 ft.)
DSBC 176
DSTC 176
DSTK 227L0,1
TK575
3BSE019956R1
Connection kit for single S100 I/O bus
extension to I/O subrack
For subrack no. 2 and 4
TK517V040: 4 m (11.7 ft.)
DSBC 176
DSTK 227L0,1
TK517V040
3BSE019957R1
Connection kit for single S100 I/O bus
extension to I/O subrack
For subrack no. 3 and 5
DSTK 195: 0.6 m (2 ft.)
DSBC 176
DSTK 227L0,1
DSTK 195
3BSE019958R1
Connection kit for redundant S100 I/O
bus extension to I/O subrack
For subrack no. 1
TK575: 2.5 m (8.3 ft.)
2xDSBC 174
2xDSTC 176
DSTK 233L0.3
2xTK575
3BSE019959R1
Connection kit for redundant S100 I/O
bus extension to I/O subrack
For subrack no. 2 and 4
TK517V040: 4 m (11.7 ft.)
2xDSBC 174
DSTK 233L0,3
2xTK517V040
3BSE019960R1
Connection kit for redundant S100 I/O
bus extension to I/O subrack
For subrack no. 3 and 5
DSTK 195: 0.6 m (2 ft.)
2xDSBC 174
DSTK 233L0,3
2xDSTK 195
3BSE019961R1
