Advant Controller 450 Product Guide
Section 4.4 Submodules
3BSE 015 953R201 Rev B 4-3
4.4 Submodules
Communication interfaces and a few other functions are realized as submodules which fits into
a slot on a submodule carrier. Modules can be exchanged while the system is running.
New modules can also be inserted live. Every unit has a red LED to indicate fault, see Table 4-1.
Table 4-1. Submodules
Submodule Description
CI531 RS-232-C communication interface for printer, EXCOM or MasterView 320.
Each interface holds two RS-232-C lines.
CS513 MasterBus 300/300E communication. Each interface holds one line.
CI532V01 RCOM/RCOM+ communication. Each interface holds two lines.
CI532V02 MODBUS communication with DB element MS. Each interface holds two lines.
CI532V03 Siemens 3964(R) communication. Each interface holds two lines.
CI534V02 MODBUS communication with DB element MVB. Each interface holds two lines.
CI534V04 Allen-Bradley DF1 communication with DB element MVB. Each interface holds two lines.
CI535V24 RCS protocol RP570 Master
CI535V29 RCS protocol RP571 Master
CI535V23 RTU protocol RP570 Slave
CI535V26 RTU protocol IEC870-5-101 Unbalanced
CI535V30 SPA Server protocol SPA Bus
CI535 Free-programmable MVI communication with DB element MS. Each interface holds two lines.
CI538 Free-programmable MVI communication with DB element MVB. Each interface holds two lines.
CI541V1 PROFIBUS-DP communication. Each interface holds one line.
CI572 L
ONWORKS Network communication, 1250 kbit/s. Each interface holds two lines.
CI543 GCOM communication. Each interface holds one line.
CI570 MasterFieldbus communication. Each interface holds one line
with cable redundancy capabilities.
CI522A Advant Fieldbus 100 communication. Each interface holds one line
with cable redundancy capabilities.
MB510 Program card interface for extra system software or application backup
PU535 Free-programmable module
