Advant Controller 450 Product Guide
Section 3.3 Optional Program Module, QC07-LIB42
3BSE 015 953R201 Rev B 3-5
3.3 Optional Program Module, QC07-LIB42
The Optional program module QC07-LIB42 extends the PC element and functional units
libraries that are included in the Basic program module with PC element for supporting
the functions below:
• Regulatory control
• Functional units, PID loop control, PIDCON
1
• Functional units, adaptive self- tuning PID loop control, PIDCONA
1
• Self-tuning adaptive control, Novatune.
The functions are realized with the PC elements in Table 3-4.
The PC elements PIDCON, RATIOSTN, MANSTN and PIDCONA are also part of the
following functional units, which is shown in Table 3-5.
Feedback control elements P-DEADB, P-1, INT, DER, PI, PIP, PDP, CON-PU1,
RAMP
Analog thyristor converter
elements
CVB-I, CVB-O
1. The PC elements and database parts of the functional units are included in QC07-BAS41 and QC07-LIB42. The
presentation and dialog support require QC07-OPF41.
Table 3-4. Additional PC elements in program module QC07-LIB42
Type PC element
Elements for functional units PIDCON, RATIOSTN, MANSTN, PIDCONA
Self-tuning controller NOVATUNE
Table 3-5. Functional units in the program module QC07-LIB42
Functional unit Description
PIDCON Regulatory controller
RATIOSTN Ratio station
MANSTN Manual station
PIDCONA Adaptive self-tuning regulatory controller
Table 3-3. Additional PC elements in program module QC07-LIB41 (Continued)
Type PC element
