Advant Controller 450 Product Guide
Section 6.13 Cabinet RM500
3BSE 015 953R201 Rev B 6-17
6.13 Cabinet RM500
Advant Controller 450 with S100 I/O is installed in RM500 cabinets. There are two different
cabinet versions, RM500V1 and RM500V2, with different foot prints. Dimensions, Table 6-19.
RM500V1 cabinets are provided with double doors (double door consists of two equal sized
doors). RM500V2 cabinets are provided with only single doors. RM500 cabinets are available
for different environmental protection classes, see Table 6-20.
6.13.1 Mounting Bars for Connection Units
Connection units are fit to mounting bars in the rear of the cabinet. Mounting bars are available
in the length of 19” or 24”. Each mounting bar normally carries two or more connection units
for S100 I/O boards. Information about how many mounting bars can be used in different
cabinets of RM500 type are given in Table 6-20.
Table 6-19. RM500 cabinets dimensions
Cabinet
Version
Width
(1)
(1) Side plates (20 mm or 0.8” each) are not included
Depth
(2)
(2) Door and back plate are included
Height
(3)
(3) Roof is included
mm inches mm inches mm inches
RM500V1 800 31.5 512 20.1 2125 83.7
RM500V2 700 27.6 637 25.1 2225 87.6
Table 6-20. RM500 cabinet protection classes
Type Protection class RM500
Ventilated, EMC-proof
(1)
(1) Standard cabinet without filter on ventilation openings. Filter is available as an option.
IP 21
Ventilated
(2)
(2) Ventilation openings are covered with metallic net to prevent insects to enter the cabinet. A heater is
included to heat the cabinet when the controller is not in use.
IP 41
Sealed IP 54
Sealed with heat exchanger
(3)
(3) Available as a standard sealed cabinet with heat exchanger as an option.
IP 54
