Advant Controller 450 Product Guide

Chapter 3 Software Components

3-6 3BSE 015 953R201 Rev B

3.4 Optional Program Module QC07-FUZ41

The Optional program module QC07-FUZ41 extends the functionality of the controller with the

FUZZYCON allowing the user to specify the control algorithm using Fuzzy Control, which is

an applied science of Fuzzy Theory. Moreover, the function supports multi variable input and

multi variable output, i.e. several controlled variables and manipulated variables can be handled

simultaneously. To the operators, FUZZYCON exposes the same “look and feel” as other

functions, for example PIDCON, with respect to object displays and dialogs. This is also true

for other run time features and most of the engineering tasks.

3.5 Optional Program Module, QC07-OPF41

The Optional program module QC07-OPF41 extends the functionality of the controller with

support for operator station functions in for example Advant Operator Workplace.

The Optional program module QC07-OPF41 extends the functionality given by the Basic

program module with the following functions:

• Functional units, binary

• Functional units, analog

• Functional units, PID loop control, PIDCON

, PIDCONA

• Functional units, motor and valve control, group start

• Support for AdvaCommand Functions

(Subscription, Order/Presentation, System Status, Status List, Trend, Event/Alarm)

• Log data storage

• Group alarm, a function in AdvaCommand Event and Alarm.

3.6 Optional Program Module, QC07-LOS41

Optional program module QC07-LOS41 extends the functionality of the controller with

MasterView 320. A VT100 terminal (or compatible) is used as operator interface.

Four such terminals can be connected to an Advant Controller 450, thus providing four local

operator workplaces. Optional program module QC07-LOS41 extends the functionality given

by the Basic program module with the following functions:

• MasterView 320

• Reports for MasterView 320.

Table 3-6. Additional PC element in program module QC07-FUZ41

Type PC element

Element for Fuzzy Control FUZZYCON

1. The PC elements and database parts are included in QC07-BAS41 and QC07-LIB42. The presentation and dialog

support are included in QC07-OPF41.
