Chapter 3 Software Components
3-4 3BSE 015 953R201 Rev B
3.2 Optional Program Module, QC07-LIB41
The Optional program module QC07-LIB41 extends the PC element library that is included in
the Basic program module with PC element for supporting the function:
• Feedback control
• Connection to analog thyristor converters.
Feedback control is realized with PC elements. The contents of PC elements in QC07-LIB41 is
shown in Table 3-3.
DAT General data base value
TEXT Text in data base
GENUSD General user-defined device controller
GENBIN User-defined on/off controller
GENCON User-defined regulatory controller
SEQ Sequence controller
GROUP Device group controller
MOTCON Motor controller
VALVECON Valve controller
DRICONE Engineered Drives Controller
DRICONS Standard Drives Controller
MOTCONI INSUM Motor Controller
Table 3-3. Additional PC elements in program module QC07-LIB41
Type PC element
Logic elements THRESH-L
Arithmetic elements MED-R, MAJ-R, LN, EXP
Multiplexers MUXGR-MI, MUXGE-MI
Time controlled elements OSC-SQW, OSC-SIN
Function generators FUNG-1V, FUNG-2V, FUNG-T
Filter elements FILT-1P, FILT-2P
Table 3-2. Functional units in the base program module QC07-BAS41 (Continued)
Functional unit Description
