ABB Advant Controller 450 Product Guide

Advant Controller 450 Product Guide
Section 5.2 Product Design
3BSE 015 953R201 Rev B 5-5
Table 5-2. RM500V2 configurations for Advant Controller 450 with S100 I/O
Configur
ation
RM500V2
cabinet
No
No. of I/O
Subracks
Remark
B1 1 0
B2 1 1
B3 1 - 2 1
B4 1 - 3 2 Only I/O 2 subrack in cabinet 3
B5 1 - 4 2 Only I/O 2 subrack in cabinet 3
B6 1 - 4 3
B7 1 - 5 4 Only I/O 4 subrack in cabinet 5
B8 1 - 6 4 Only I/O 4 subrack in cabinet 5
B9 1 - 6 5
