Advant Controller 450 Product Guide
Section 4.9.3 Configuration Alternatives
3BSE 015 953R201 Rev B 4-13
4.9.3 Configuration Alternatives
There are two configurations of the main power supply: with or without redundancy, as depicted
in Figure 4-16 and Figure 4-17. When also taking the type of mains supply type into
consideration there will be a total of six alternative configurations of the power supply.
Please see Table 4-4 for an overview.
Table 4-4. Different power supply arrangements for Advant Controller 450 with S100 I/O
Power supply
Redundancy
Configuration Remark
No Yes
120/230 V a.c. x Figure 4-16
24/48 V d.c. x Figure 4-16
24 V d.c. x Figure 4-16 No galvanic isolation
120/230 V a.c. x Figure 4-17
24/48 V d.c. x Figure 4-17
120/230 V a.c. x Figure 4-17 Two different supply
networks
Figure 4-16. Block diagram of power supply solution without redundancy
Unstabilized
power supply,
d.c./d.c.
converter or
Energy
reservoir
Power
switch
Power supply
+24 V Load
Voltage
Regulator
SR511
