ABB Advant Controller 450 Product Guide

Advant Controller 450 Product Guide
3BSE 015 953R201 Rev B 8-33
8.6.13 Cabinets
Table 8-55. RM500V1 Cabinets With=800 mm (31.5”), Depth=512 mm (20.2”)
Description Consists of Article No.
Single cabinet ventilated IP21, height: 2125 mm
(83.7”) for cabinet no. 1, 4, 6 or 7
RM501 3BSE016045R1
Single cabinet ventilated IP21, height: 2125 mm
(83.7”) for cabinet no. 2, 3 or 5
RM511 3BSE016054R1
Single cabinet ventilated IP41, height: 2125 mm
(83.7”) for cabinet no. 1, 4, 6, or 7
RM502 3BSE016046R1
Single cabinet ventilated IP41, height: 2125 mm
(83.7”) for cabinet no. 2, 3 or 5
RM512 3BSE016055R1
Single cabinet sealed IP54, height: 2125 mm
(83.7”) for cabinet no. 1, 4, 6 or 7
RM503 3BSE016047R1
Single cabinet sealed IP54, height: 2125 mm
(83.7”) for cabinet no. 2, 3 or 5
RM513 3BSE016056R1
Table 8-56. RM500V2 Cabinets
Width=700 mm (27.6”), Depth=637 mm (25.1”), Height=2225 mm (87.6”)
Description Consists of Article No.
Single cabinet ventilated IP21,
for cabinet no. 1, 3 or 5
RM507 3BSE016051R1
Single cabinet ventilated IP21,
for cabinet no. 2, 4 or 6
RM517 3BSE016060R1
Single cabinet ventilated IP41,
for cabinet no. 1, 3 or 5
RM508 3BSE016052R1
Single cabinet ventilated IP41,
for cabinet no. 2, 4 or 6
RM518 3BSE016061R1
Single cabinet sealed IP54,
for cabinet no. 1, 3 or 5
RM509 3BSE016053R1
Single cabinet sealed IP54,
for cabinet no. 2, 4 or 6
RM519 3BSE016062R1
