ABB Advant Controller 450 Product Guide

Advant Controller 450 Product Guide
Chapter 6 Technical Data and Performance
6-14 3BSE 015 953R201 Rev B
MasterView 320 Basic requirements for QC07-LOS41 1 x 240
No. of displays
(3)
x 2
No. of MasterView 320 with event lists
(4)
x 9
AdvaCommand,
IMS Station or
MV800/1
Basic requirement for QC07-OPF41 1 x 799
No. of trend data storage logs
(5)
x 12
Group alarm, No. of group objects
No. of group members
x 0.13
x 0.09
MasterBatch 200/1 Basic requirement for QC07-BAT41 1 x 418
No. of SECCONx1.7+OPCONx6.0+
TANKCONx1.8
x 1
No. of processes
(6)
x 25
Profibus DP No. of Profibuses x 1.2
Number of Profibus slaves x 0.8
L
ONWORKS
Network
No. of LONWORKS Communication
Modules (CI572)
x 65
No. of L
ONWORKS Devices x 0.2
No. of L
ONWORKS variables
(input and outputs)
x 0.06
No. of L
ONWORKS multiple
network variables
x 0.33
No. of L
ONWORKS Event Treat x 0.14
No. of MasterBus 300/300E, RCOM/RCOM+, GCOM and
MultiVendor Interface
x 8
Telecontrol &
SPA Bus
See respective Product Guide
User Defined
PC elements
Basic requirements for QC07-UDP41 1 x 132
Storage of user defined PC elements
(7)
1x 150
Space for storage of User Diskette contents
(7)
x 100
Basic requirements for QC07-LIB41 1 x 32
Basic requirements for QC07-LIB42 1 x 479
Table 6-14. Calculation of RAM requirement (Continued)
Object type Remark Total
Factor
(kbytes)
RAM req.
