CHAPTER 3
Preparing for installation
This chapter provides information relevant to the steps that should be performed prior to installing the
CoreSense sensor.
Tools for installation
Here are the various tools necessary to install the CoreSense system.
Tools supplied by ABB
4 mm Allen key
5 mm Allen key
Spare Parts
O-ring No. 1 (Sensor enclosure) Buna-N o-ring no: AS568A DASH NUMBER 269, A50 durometer
O-ring No. 2 (Sensor brass fitting)
already installed on sensor
Metric Buna-N o-ring 3 mm width, 50 mm inside diameter
Plugs To cover unused cable gland ports
For sampling
Additional tools (not supplied by ABB)
Laptop with Internet
Explorer 9 or above (for
sensor commissioning)
Straight Ethernet cable (for
sensor commissioning)
