10 EL3000 CONTINUOUS GAS ANALYZERS | CI/EL3000-EN REV. C
… 2 Use in potentially explosive atmospheres
Explosion proof design in degree of protection II 3G
Note
The version for the measurement of flammable gases and the explosion-proof design in degree of protection II 3G is designed for
various variants of the gas analyzer and for different applications.
Description
The model EL3040 gas analyzer in degree of protection II 3G is
tested for explosion protection and is suited for use in
potentially explosive atmospheres, with consideration of the
specification and the special conditions (see Special conditions
on page 11).
The gas analyzer is intended for indoor installation only.
In the gas analyzer, the Uras26, Magnos206, Magnos28 and
Caldos27 analyzers can be installed individually and in these
combinations: Uras26 with Magnos206 or Magnos28 or Caldos27
or oxygen sensor.
The gas analyzer may be used for measurement of non-
flammable gases and vapors.
The gas analyzer is marked in accordance with the European
directive 2014/34/EU as:
II 3G Ex ec nC IIC T4 Gc
In undisturbed operation there cannot be any sparking, arcing or
impermissible temperatures inside the device.
Explosion protection through: increased safety as well as
gasketed or encapsulated equipment.
Type examination certificate no. BVS 16 ATEX E 085 X.
Note
The measurement function of the analyzer is not part of the type
examination certificate.
Characteristic values
System bus, computer
interfaces
to 240 V AC
-flammable sample gas
Maximum 1600 hPa absolute pressure
All other analyzer modules:
hPa absolute pressure or maximum
100
hPa gauge pressure
Flow rate (gas output
atmospheric)
l/h
5 to 45 °C (41 to 113 °F)
