Special conditions for the model EL3040 gas analyzer in
degree of protection II 3G
Protection against mechanical influences
Due to the low mechanical stability of the viewing glass, the gas
analyzer must be designed and operated in such a way that
mechanical damage to the viewing glass is excluded with an
energy greater than 2 J.
UV radiation protection
Due to the low UV resistance of the plastic parts of the housing,
the gas analyzer must be designed and operated in such a way
that the effect of UV radiation can be excluded.
Housing design
Model
Housing design
IP rating
Weight
EL3020
19” housing
IP 20
approx. 7 to 15 kg
EL3040
Wall
-mount housing
IP
65 approx. 13 to 21
kg
Power supply
Electric information (entire device)
The power supply built into the system housing is used to supply
24 V DC to the analyzer module and the associated electronics.
Input voltage
100 to 240 V AC, −15/+10 %;
50 to 60 Hz, ±3 Hz
Power
Maximum 187 VA (without heaters from Fidas24)
Connection
3-pole cold device plug in accordance with EN 60320-1/C14
(Power cable included in scope of supply)
Battery
Lithium 3 V type Varta CR2032 button cell, to supply the
integrated clock during a voltage drop
Electric information (analyzer modules)
Input voltage
24 V DC, ±5 %
Power consumption analyzer modules (DC)
Uras26:
Max. 95 W
Magnos206:
max. 50
W
Limas23:
max. 100 W
ZO23:
max. 35 W
Magnos28:
max. 50
W Caldos27:
max. 17
W
Magnos27:
max. 35 W
Fidas24:
max. 50 W
Fidas24 Analyzer Module (AC)
Detector and Sample Gas Inlet Heaters
Input voltage
115 V AC or 230 V AC, ±15
% (max. 250 V AC), 50 to
60 Hz, ±3 Hz
Power consumption
125
VA for detector
125 VA for sample gas inlet (option)
Connection
4
-pin male connector
(connection cable included in scope of supply)
