ABB EasyLine EL3000 Manual

EL3000 CONTINUOUS GAS ANALYZERS | CI/EL3000-EN REV. C 95
Standard assignment of digital inputs and digital outputs
Function
Digital I/O Module 1
Digital I/O Module 2
Failure
Maintenance required
Maintenance mode
Overall status
DO1
Start automatic calibration
DI1
Stop automatic calibration
Disable automatic calibration
DI2
Sample gas valve
DO4
Zero point gas valve
Span gas valve 1
Span gas valve 2
Span gas valve 3
Span gas valve 4
Span gas valve 5
Pump, on/off*
Limit 1
DO2
Limit 2
DO3
Limit 3
DO1
Limit 4
DO2
Limit 5
DO3
Limit 6
DO4
Limit 7
Limit 8
Limit 9
Limit 10
Measuring range switch
-over
Measuring range feedback
Measuring component switch
-over
Measuring component feedback
Bus
-DI 1
Bus-DI 2
Bus
-DI 3
Bus-DI 4
Bus
-DI 5
Bus-DI 6
Bus
-DI 7
Bus-DI 8
External failure**
DI3
External maintenance request**
DI4
* If a pump is installed (‘Integral gas feed’ option – only in model EL3020, not for Limas23, ZO23, Fidas24).
** Multiple external status signals can be configured depending on the number of free digital inputs.
Note
The allocation of the terminals (see Operating instruction) can be changed in the configurator.
