EL3060 CONTINUOUS GAS ANALYZERS | OI/EL3060-EN REV. A 15
Case purging
In order to protect the electronic assemblies from an ingressing aggressive
atmosphere or corrosive sample gas components, the flameproof case can
be purged with air or nitrogen.
The purge gas is fed in and conducted away via two flame barriers, which are
open on the inside of the flameproof case.
Remark: The case purging has no meaning in the sense of a pressurized en-
closure to IEC/EN 60079-2.
Explosion protection
The gas analyzers are designed for use in hazardous areas. They are certified
in accordance with the European Directive 2014/34/EU ("ATEX Directive")
and the pertinent IEC standards.
The housings are designed as field housings in the type of protection
"Flameproof Enclosure 'd'". They comply with the requirements of the explo-
sion group IIC. As a result, the gas analyzers can also be used in atmos-
pheres containing hydrogen or acetylene.
Certification to ATEX Directive
EL3060-CU control unit (with or without Magnos206, Magnos28, Caldos25,
Caldos27 analyzers)
EC Type Examination Certificate BVS 08 ATEX E 048 X
Marking
II 2G Ex db e IIC T4 Gb
Analyzer unit EL3060-Uras26
EC Type Examination Certificate BVS 08 ATEX E 055 X
Marking
II 2G Ex db IIC T4 Gb
Remark: The measurement function according to Directive 2014/34/EU Annex
II, Paragraph 1.5.5 is not an object of these EC type examination certificates.
Certification to IEC standards
EL3060-CU control unit (with or without Magnos206, Magnos28, Caldos25,
Caldos27 analyzers)
IECEx Certificate of Conformity IECEx BVS 13.0037X
Marking Ex db e IIC T4 Gb
Analyzer unit EL3060-Uras26
IECEx Certificate of Conformity IECEx BVS 13.0056X
Marking Ex db IIC T4 Gb
NOTES
The certificates can be found on the DVD-ROM which is enclosed with the
gas analyzer.
Please note the "Information for the installation, maintenance and repair of
electrical installations in hazardous areas" (see page 11).
