EL3060 CONTINUOUS GAS ANALYZERS | OI/EL3060-EN REV. A 53
Information on the concept of operation
Concept of operation
The concept of operation of the gas analyzers is designed in such a way that
the functions required in normal operation are operated and configured
directly on the device. On the other hand, the functions which are only sel-
dom required, e.g. during the commissioning of the device, are configured
offline using the software tool ECT ("EasyLine Configuration Tool" on the
enclosed DVD-ROM, also referred to as "configurator" in this instruction) and
then loaded into the gas analyzer.
Overview of the functions
Function Device Configurator Modbus
Automatic calibration:
Start/cancel automatic calibration (see page 66) (also possible via digital
inputs)
X X
Activate/deactivate cyclically time-controlled automatic calibration (see
page 62)
X X X
Cycle time of the automatic calibration (see page 63) X
End-point calibration together with zero-point calibration (see page 63) X X
Date and time of the next automatic calibration (see page 63) (start of
the cycle)
X X
Test gas concentration (see page 61) X X X
Purging times (see page 63) X X
Output current response (see page 63) (for automatic and manual cali-
bration)
X
Calibration method (see page 63) (Magnos206, Magnos28) X X
Manual calibration:
Calibration method (see page 67) X X
Test gas concentration (see page 61) X X
Execute calibration (see page 68) X
Maintenance functions:
Calibration reset (see page 119) X
Calibration of the pressure sensor (see page 122) / Set atmospheric
pressure value
X
Measuring calibration cell (see page 120) (Uras26) X
Drift, delta drift (see page 121) (display) X X
Software version (see page 127) X X
Status information (see page 132) X X
Component parameters:
Range limits (see page 80) X X
Alarm value parameters (see page 89) X
Low pass time constant (see page 90) (T90 time, filter) X X
Active component (see page 91) X X X
Modbus parameters
1
X
Profibus parameters
2
X
Ethernet parameters (see page 96) X X
Signal inputs and outputs (see page 95) (I/O connections) X
1
For detailed information on "Modbus", refer to the Technical Information "EL3000,
EL3060, EL3010-C – Modbus".
2
For detailed information on "Profibus", refer to the Technical Information "EL3000,
EL3060 – PROFIBUS DP/PA Interface".
