EL3060 CONTINUOUS GAS ANALYZERS | OI/EL3060-EN REV. A 31
1
) Assignment of the
2
) gas connections
3
) see
4
) analyzer data sheet (see page 33)
5
Purge gas inlet
1)
6
Purge gas outlet
1)
7
Connection of the pressure sensor
2)
8
Conduit for data transmission cable
9
Conduit for 24 VDC connecting cable
10
Connection for equipotential bonding
1) Option
2) The connection of the pressure sensor (see page 26) must not be
connected to the sample gas feed path when measuring flammable or
corrosive gases.
Design of the gas connections: Internal flame barriers made of stainless
steel 1.4571 (SAE 316Ti) with ⅛ NPT female thread
Connecting cable: The non-detachable connecting cables for data transmis-
sion and the 24 V DC supply are an integral component of the flameproof
case of the analyzer unit. In each case, they are 10 m long and may not be
shortened to a length of less than 1 m.
NOTE
The extra space required below the analyzer unit for the connecting cables
(approx. 10 cm) and above the analyzer unit for opening the case (approx.
40 cm) must be considered.
