EL3060 CONTINUOUS GAS ANALYZERS | OI/EL3060-EN REV. A 29
Standard version: Version for measuring gases under
positive pressure:
1
Sample gas inlet
1)
Vent
1)
2
Sample gas outlet
1)
Sample gas outlet
1)
3
Purge gas inlet
2)
Purge gas inlet
2)
4
Purge gas outlet
2)
Sample gas inlet
1)
5
Connection of the pressure
sensor
3)
Connection of the pressure sensor
3, 4)
or purge gas outlet
2)
6
Socket-head hex screw for securing the case cover
7
Case cover
8
Screwed cable glands M20
9
Screwed cable glands M16
10
Terminal housing with terminal strip (see page 39)
11
Connection for equipotential bonding
1) If a Magnos206 or Magnos28 or Caldos27 or Caldos25 analyzer has
been installed in the control unit
2) Option
3) Option. The pressure sensor (see page 26) connection must not be
connected to the sample gas feed path when measuring flammable or
corrosive gases.
4) Not in the version with housing purge
Design of the gas connections: Internal flame barriers made of stainless
steel 1.4571 (SAE 316Ti) with ⅛ NPT female thread
NOTE
Bear in mind the extra space required for the connection leads under and
immediately to the left and right of the control unit (approx. 10 cm in each
case).
