36 Start-up
04 DRIVE PROFILE Defines the communication used between the
module and the drive (not fieldbus and module).
If a drive supports more than one drive profile,
this parameter is used to select the preferred
profile. Presently, to use the ODVA and ABB
Drives profiles, the drive must support a native
profile (eg, DCU or FBA). Transparent16 and
Transparent32 profiles may be used with any
drive profile.
0 =
Native
prof
ACS355:
FB PAR 4
ACSM1:
FBA PAR4
ACS850/ACQ810:
FBA par4
ACS880:
Drive profile
0 = Native prof Native profile of the drive selected
05 ODVA STOP
FUNC
Used with the ODVA AC/DC drive profile.
Determines how the motor is stopped when a
stop command is received via DeviceNet.
0 = Ramp
stop
ACS355:
FB PAR 5
ACSM1:
FBA PAR5
ACS850/ACQ810:
FBA par5
ACS880:
ODVA stop func
0 = Ramp stop Motor decelerates along the active deceleration
ramp.
1 = Coast stop Motor comes to a stop by coasting.
No. Name/Value Description Default
