Start-up 37
06 OUTPUT
INSTANCE
Configures the output assembly instances used
by the adapter module. Tables below list the
supported assemblies and allowed
combinations. For the descriptions of the
assembly instances, see section Assembly
objects on page 98.
20
ACS355:
FB PAR 6
ACSM1:
FBA PAR6
ACS850/ACQ810:
FBA par6
ACS880:
Output instance
No. Name/Value Description Default
Name Output
instance
Input
instance
Default
input
size
(bytes)
Profile
Basic speed control 20 70 4 ODVA AC/DC drive
Extended speed
control
21 71 4 ODVA AC/DC drive
Basic speed and
torque control
22 72 6 ODVA AC/DC drive
Extended speed and
torque control
23 73 6 ODVA AC/DC drive
Basic speed control
plus drive parameters
120 170 24 ODVA AC/DC drive
Extended speed
control plus drive
parameters
121 171 24 ODVA AC/DC drive
Basic speed and
torque control plus
drive parameters
122 172 26 ODVA AC/DC drive
Extended speed and
torque control plus
drive parameters
123 173 26 ODVA AC/DC drive
ABB Drives profile
with set speed
801 851 4 ABB Drives
ABB Drives profile
with set speed and
set torque
802 852 6 ABB Drives
(continued)
