ABB FDNA-01

Start-up 41
10 ODVA SPEED
SCALE
Defines the speed scale in the ODVA AC/DC
drive profile. Units of reference and actual
speeds for the ODVA AC/DC drive profile are
given by the formula below. No effect on the
ABB Drives profiles.
Note: While a wide range of resolutions may be
configured, the actual performance is limited to
the performance capabilities of the drive.
Speed unit = RPM X 2
(-1 X ODVA speed scale value)
128
ACS355:
FB PAR 10
ACSM1:
FBA PAR10
ACS850/ACQ810:
FBA par10
ACS880:
ODVA speed scale
Table below shows how the values of drive
parameter ODVA SPEED SCALE correspond
to the ODVA Speed Scale units.
123…133 Speed scale value of the drive parameter
No. Name/Value Description Default
ODVA speed scale value
1)
Speed scale value of
drive parameter
2)
Unit
-5 123 32 RPM
-4 124 16 RPM
-3 125 8 RPM
-2 126 4 RPM
-1 127 2 RPM
0 (default) 128 1 RPM
1 129 0.5 RPM
2 130 0.25 RPM
3 131 0.125 RPM
4 132 0.0625 RPM
5 133 0.03125 RPM
1)
Use the ODVA speed scale value when reading/writing parameter ODVA
SPEED SCALE via AC/DC-drive object, class 2Ah. When written via the
AC/DC drive object, the new value takes effect immediately.
2)
Use the speed scale value of the drive parameter when reading/writing
parameter ODVA SPEED SCALE via the drive control panel, Drive parameter
object, Class 90h and Fieldbus configuration object 91h. When written via
these methods, the new value takes effect after the drive is repowered or a
“Fieldbus Adapter Parameter refresh” is given.
