40 Start-up
08 INPUT INSTANCE Configures the input assembly instances used
by the adapter module. See parameter 06
OUTPUT INSTANCE.
70
ACS355:
FB PAR 9
ACSM1:
FBA PAR9
ACS850/ACQ810:
FBA par9
ACS880:
Input instance
For alternative values, see parameter 06
OUTPUT INSTANCE.
09 INPUT NUM
PARS
See parameter 07 OUTPUT NUM PARS.
Note: This parameter is only used when the
input assembly instance is 170, 171, 172, 173,
951, 952, 961, 962, 971, 972. It must always be
set to the default, 10, except as described in
Appendix A – Varying the number of drive
parameters.
10
ACS355:
FB PAR 9
ACSM1:
FBA PAR9
ACS850/ACQ810:
FBA par9
ACS880:
Input num pars
1…10 Number or drive parameter values to be
included in the assembly instance
No. Name/Value Description Default
