Start-up 61
52.03 FBA data in3 105 Motor current percent
52.04 FBA data in4 107 DC voltage
52.05 FBA data in5 0 DC voltage - LSW
52.06 FBA data in6 108 Encoder1 speed
52.07 FBA data in7 0 Encoder 1 speed - LSW
52.08 FBA data in8…
52.10 FBA data in10
0
53.01 FBA data out1 2204 Acc time 2
53.02 FBA data out2 0 Acceleration time 2 - LSW
53.03 FBA data out3 2205 Dec time 2
53.04 FBA data out4 0 Deceleration time 2 - LSW
53.05 FBA data out5 2606 Const speed1
53.06 FBA data out6 2607 Const speed2
53.07 FBA data out7 2608 Const speed3
53.08 FBA data out8…
53.10 FBA data out10
0
51.27 FBA par refresh 1 = Refresh Validates the FDNA-01
configuration parameter settings.
10.01 Ext1 start func FB Selects the fieldbus interface as the
source of the start and stop
commands for external control
location 1.
10.04 Ext2 Start func 3 = FB Selects the fieldbus as the source
for start and stop commands for
external control location EXT2 (only
with ACS850).
12.01 Ext1/Ext sel P.2.22.15 = P.FBA
main cw.15
Selects FBA Control word bit 15 as
the source for external control
location EXT1/EXT2 selection (only
with ACS850).
12.03 Ext1 ctrl mode 1 = Speed Selects speed as the operating
mode for external control location
EXT1.
Drive parameter Setting for
ACS850/ACQ810
drives
Description
