62 Start-up
The start sequence for the parameter example above is given
below.
Control word:
• 47Eh (1150 decimal) –> READY TO SWITCH ON
• 47Fh (1151 decimal) –> OPERATING (Speed mode)
or
C7Fh (3199 decimal) –> OPERATING (Torque mode in
ACS850).
12.05 Ext2 ctrl mode 2 = Torque Selects torque as the operating
mode for external control location
EXT2 (only with ACS850).
16.15 Menu set sel
(ACS850)
16.21 Menu selection
(ACQ810)
2 = Load long
(ACS850)
2 = Full (ACQ810)
Load long parameter list. All
parameters will be displayed.
21.01 Speed ref1 sel FB Selects the fieldbus reference 1 as
the source for speed reference 1.
24.01 Torq ref1 sel FBA ref2 Selects fieldbus reference 2 as the
source of the torque reference 1
(only with ACS850).
1)
Read-only or automatically detected/set
Drive parameter Setting for
ACS850/ACQ810
drives
Description
