Communication profiles 89
2 OFF3_
CONTROL
1 Continue operation (OFF3 inactive).
0 Emergency stop, stop within time defined
with the drive parameter. Proceed to OFF3
ACTIVE; proceed to SWITCH-ON
INHIBITED.
Warning: Ensure motor and driven
machine can be stopped using this stop
mode.
3 INHIBIT_
OPERATION
1 Proceed to OPERATION ENABLED.
Note: Run enable signal must be active;
see drive documentation. If the drive is set
to receive the Run enable signal from the
fieldbus, this bit activates the signal.
0 Inhibit operation. Proceed to OPERATION
INHIBITED.
4RAMP_OUT_
ZERO
1 Normal operation. Proceed to RFG:
OUTPUT ENABLED.
0 Force the Ramp Function Generator output
to zero. Drive ramps to stop (current and
DC voltage limits in force).
5 RAMP_HOLD 1 Enable ramp function.
Proceed to RFG: ACCELERATOR
ENABLED.
0 Halt ramping (Ramp Function Generator
output held).
6RAMP_IN_
ZERO
1 Normal operation. Proceed to
OPERATION.
Note: This bit is effective only if the
fieldbus interface is set as the source for
this signal by drive parameters.
0 Force the Ramp Function Generator input
to zero.
Bit Name Value STATE/Description
