90 Communication profiles
7 RESET 0=>1 Fault reset if an active fault exists. Proceed
to SWITCH-ON INHIBITED.
Note: This bit is effective only if the
fieldbus interface is set as the source for
this signal by drive parameters.
0 Continue normal operation.
8…9 Reserved.
10 REMOTE_
CMD
1 Fieldbus control enabled.
0Control
word and reference not getting
through to the drive, except for CW bits
OFF1, OFF2 and OFF3.
11 EXT_CTRL_
LOC
1 Select External Control Location EXT2.
Effective if the control location
parameterized to be selected from the
fieldbus.
0 Select External Control Location EXT1.
Effective if the control location
parameterized to be selected from the
fieldbus.
12…
15
Reserved.
Bit Name Value STATE/Description
