176 EtherNet/IP – Communication profiles
10 ABOVE_
LIMIT
1 Actual frequency or speed equals or
exceeds supervision limit (set by drive
parameter). Valid in both directions of
rotation.
0 Actual frequency or speed within supervision
limit
11 EXT_CTRL_
LOC
1 External Control Location EXT2 selected.
Note concerning ACS880: This bit is
effective only if the fieldbus interface is set
as the target for this signal by drive
parameters. User bit 0 selection (06.33)
0 External Control Location EXT1 selected
12 EXT_RUN_
ENABLE
1 External Run Enable signal received.
Note concerning ACS880: This bit is
effective only if the fieldbus interface is set
as the target for this signal by drive
parameters. User bit 1 selection (06.34)
0 No External Run Enable signal received
13…
14
Reserved
15 FBA_
ERROR
1 Communication error detected by fieldbus
adapter module
0 Fieldbus adapter communication OK
Bit Name Value STATE/Description
