9.1.1 Customer spare part set (97070)
The customer spare part set (97070) is required for the operations described. These parts
are only available in a complete set (see chapter Ordering spare parts →75). The content of
the set can be viewed via the following QR code or URL link.
http://www.abb.com/abblibrary/DownloadCenter/?CategoryID=9AAC179494&View=Result&Docu-
mentKind=Catalogue&QueryText=spare+parts+set&SortBy=Score&CountryCode=CH&Addition-
alLanguage=*
Identification of the assembly devices
Not all assembly devices are marked with a part number. Identification is guaranteed by the
tool list. This list is enclosed with the toolbox.
WARNING
Servicing the assembly devices
Assembly devices must be checked for damage before and after use.
u Visually inspect for corrosion, cracks, deformation and wear.
u Damaged assembly devices must no longer be used and must be re-
placed.
Tightening torques for assembly devices
Unless described otherwise, the screws and nuts of the assembly devices supplied by ABB
must be tightened so they rest firmly against the surface.
