KNX Technical Reference Manual
ABB i-Bus
®
KNX Yucus
36
This parameter is used to define what value is to be display at the sub display. Value has
to be transmitted by an external device and receive by the control element via the KNX
bus line.
12.6.2 Common parameter – Time format
Options 24 hr
12 hr
Note: This parameter is only visible if “– Sub display” is activate and selection is
“Time”
This parameter is used to specify the time format in the sub display.
12.6.3 Object no
LCDSD: Value for subdisplay 2 byte DPT 9.001 C, W, T, U
LCDSD: Value for subdisplay
LCDSD: Value for subdisplay 2 byte DPT 7.001 C, W, T, U
LCDSD: Value for subdisplay
LCDSD: Value for subdisplay
LCDSD: Value for subdisplay 3 byte DPT 10.001 C, W, T, U
12.7 Application “1-button switching”
When the 1st or 2nd button is actuated or released, a switching telegram is sent out. In
each case, the application makes a separate set of parameters and communication
objects available for the 1st and the 2nd button. The other side of the button can be
assigned a further "button-oriented" function.
12.7.1 Common parameter – Reaction on rising edge
Options On
Off
Alternating on/off
The application can differentiate between the operation and the releasing of the button.
An operation is designate as "Rising edge" and the releasing is designate as "Falling
edge". The application "1-button switching" makes two separate "Switching"
communication objects available for the left or right side of the button. The value 1 is
always sent out on the first object (Value 1) and the value 2 is always sent out on the
second object (Value 2). The "Reaction to rising edge" parameter specifies whether the
"Value 1 for rising edge" or the "Value 2 for rising edge" is sent out for rising edge.
Alternatively, Value1/Value2 can also be alternatingly set for a rising edge, i.e. after Value
1 was sent (or received), a renewed operation will send out Value 2. After it is operate
