KNX Technical Reference Manual
ABB i-Bus
®
KNX Yucus
41
slat position object of a blind actuator. Percentage values from 0% to 100% can be set in
1% steps. The value 0% means opened completely; the value 100% means closed
completely.
12.9.8 Extended parameter – Value for slat position up (%)
Note: This parameter is only visible if the “Function switchover shutter/ roller
blind” parameters is set on shutter
The position that a connected blind slat is to be close to is set via this parameter. The
associated 1-byte "Adjust" communication object must hereby be connected with a 1-byte
slat position object of a blind actuator. Percentage values from 0% to 100% can be set in
1% steps. The value 0% means opened completely; the value 100% means closed
completely.
12.9.9 Objects no for “Function switchover shutter
Object name Data type Flags
Move blinds / shutter up-
down
1 Bit DPT 1.008 C, W, T, U
Move blinds / shutter up-
down
1 byte DPT 5.001 C, W, T, U
Slats adjust / stop up-down 1 byte DPT 5.001 C, W, T, U
12.9.10 Objects no for “Function roller blind
Object name Data type Flags
Move blinds / shutter up-
1 Bit DPT 1.008 C, W, T, U
Stop up-down 1 Bit DPT 1.007 C, W, T, U
12.10 Application “1-button value transmitter”
The application "1-button value transmitter" makes its own communication object
available for the left or right side of the button. The bit size of the communication object
is specified via the "Object type" parameter. For the most diverse applications, the bit size
of the communication objects can be adapted from "1-bit" up to "4-byte unsigned" via
"Object type".
12.10.1 Common parameter – Object type
Options 1 bit
1 byte 0 - 100%
1 byte (0 - 255)
2-byte float
2-byte signed
2-byte unsigned
