The "Value of the output object for logic untrue" is set to "0" by default. I.e. as soon as
the function is not fulfill, a logical "0" is present on the output. The value that is present
on the output for unfulfilled logic can be set via the setting "Defined via output default
value untrue".
Note: The output value is also set to "0" with the output object size of 1-byte for the
standard setting (output object is set to 0) and an unfulfilled function.
12.26.13 Object no
Object name Data type Flags
Output
1
bit DPT 1.001
C, R, T
Output
1 bit DPT 5.010
C, R, T
Input 1 bit DPT 2.001 C, W, U
Input
1 bit DPT 5.010
C, W, U
Input 1 bit DPT 2.001 C, W, U
Input
1 bit DPT 5.010
C, W, U
Input 1 bit DPT 2.001 C, W, U
Input
1 bit DPT 5.010
C, W, U
Input
1 bit DPT 2.001
C, W, U
Input 1 bit DPT 5.010 C, W, U
Input
1 bit DPT 2.001
C, W, U
Input 1 bit DPT 5.010 C, W, U
Input
1 bit DPT 2.001
C, W, U
Input 1 bit DPT 5.010 C, W, U
Input 1 bit DPT 2.001 C, W, U
Input
1 bit DPT 5.010
C, W, U
Input 1 bit DPT 2.001 C, W, U
Input
1 bit DPT 5.010
C, W, U
Input 1 bit DPT 2.001 C, W, U
Input
1 bit DPT 5.010
C, W, U
Input
1 bit DPT 2.001
C, W, U
Input 1 bit DPT 5.010 C, W, U
12.27 Application “Gate”
The "Gate" application allows specific signals to be filter and the signal flow to be
temporarily blocked. The function has three communication objects: "Control input",
"Input" and "Output".
The input or output object can assume different sizes. The bit size can be freely assigned
with the "Not assigned" setting. This means that the first internal or external group
address/action that is assigned and already connected to some other communication
object will specified the size.
The control can occur from "Input to output" or also from "Output to input", provided the
control input allows this. Enabling via the control input can occur via an ON or an OFF
telegram.
