ABB i-bus KNX Yucus YUB/U1.0.1 Series User Manual

KNX Technical Reference Manual
ABB i-Bus
®
KNX Yucus
71
12.22.5 Extended Parameter –Object values
Options Normal
Inverse
The object values can be sent "normal" or "inverse" via their associated 1-bit
communication objects. If the parameter "Object values" is set to "inverse" then all 1-bit
communication objects of the individual levels, send out their values inverted.
12.22.6 Extended Parameter – Bit pattern of object values
Options x of n
1 of n
12.22.7 The levels can be switch in two different bit patterns:
x of n (for 5 objects, object 0 to 4)
1 of n (for 5 objects, object 0 to 4)
00000
10000
11000
11100
11110
11111
00000
10000
01000
00100
00010
00001
12.22.8 Objects no
Object name
Data type
Flags
Switching stage 1 1 Bit DPT 1.001 C, W, T
Switching stage 2
1 Bit DPT 1.001
C, W,
T
Switching stage 3 1 Bit DPT 1.001 C, W, T
Switching stage 4
1 Bit DPT 1.001
C, W,
T
Switching stage 5 1 Bit DPT 1.001 C, W, T
12.23 Application “Left Label / Right Label / Center Label”
Left Label, Right Label, Center Label application is available within each rocker
application, this application is used to specify the control element digital label of row
1/2/3/4. The digital label can be used for labeling the function of the designated rocker,
indicate the status of the designated rocker in different colour or be an orientation
illumination of the designated rocker.
Options Label functionality
Inactive
12.23.1 Common parameter – Label type
Options Symbol
Description
This parameter is used to specify the type of display for the digital label. The digital label
can be in the form of either symbol or wording description.
