Note”: This parameter is only visible if the "Reaction at failing edge" parameter
is set on either "Value 2" or "Alternating Value1/Value2". The options are dependent on
the setting of the "Object type for failing edge" parameter.
Value 2 options are dependent on the setting of the "Object type for failing edge"
parameter.
– 1 bit: switching functions (e.g. On/Off, enable/blocked, true/untrue)
– 1 byte 0 - 100%: percentage values (0 = 0%, 255 = 100%)
– 1 byte 0 - 255: arbitrary values from 0 to 255
– 2-byte float: floating point value (physical values such as temperature or brightness) -
671088.64 to 671088.64
– 2-byte signed: arbitrary values from -32768 to +32767
– 2-byte unsigned: arbitrary values from 0 to 65,535
– 4-byte float: floating point value (physical values) -4000000 to 4000000
– 4-byte signed: arbitrary values from -2147483648 to 2147483647
– 4-byte unsigned: arbitrary values from 0 to 4294967295
12.11.9 Object no
Object name Data type Flags
Switching (rising edge) 1 byte DPT 5.001 C, W, T, U
Switching (rising edge) 2 byte DPT 9.xxx C, W, T, U
Switching (rising edge) 2 byte DPT 8.001 C, W, T, U
Switching (rising edge) 4 byte DPT 14.xxx C, W, T, U
Switching (rising edge) 4 byte DPT 12.001 C, W, T, U
Switching (failing edge) 1 byte DPT 5.010 C, W, T, U
Switching (failing edge) 2 byte DPT 8.001 C, W, T, U
Switching (failing edge) 4 byte DPT 14.xxx C, W, T, U
12.12 Application “1-button light scene extension unit with memory function”
When a button is activated, a predefined light scene number is call backlight up. In each
case, the application makes a separate set of parameters and communication objects
available for the 1
st
and the 2nd button. The application makes it possible to call up a light
scene via one button side while the other button side can be assigned with a further
"button-oriented" function. The user has the option to trigger a light scene memory
command via a long actuation of the button.
