ABB i-bus KNX Yucus YUB/U1.0.1 Series - Page 41

KNX Technical Reference Manual
ABB i-Bus
®
KNX Yucus
40
Roller blind
The " Function switchover roller blinds/shutters" specifies whether a shutter or roller blind
is to be driven by a button operation. With the "blind" setting, the value for the slats
adjustment does not apply.
12.9.5 Extended parameter – Value for position down (%)
Options 0..100%
Note: This parameter is only visible if the “Function switchover shutter/ roller blind”
parameters is set on shutter
The position that a connected blind is to be lowered to is set via this parameter. The
associated 1-byte "Move" communication object must hereby be connected with a 1-byte
position object of a blind actuator. Percentage values from 0% to 100% can be set in 1%
steps. The value 0% means travel up completely; the value 100% means travel down
completely.
12.9.6 Extended parameter – Value for position up (%)
Options 0..100%
Note: This parameter is only visible if the “Function switchover shutter/ roller
blind” parameters is set on shutter
The position that a connected blind is to be raised to is set via this parameter. The
associated 1- byte "Move" communication object must hereby be connected with a 1-byte
position object of a blind actuator. Percentage values from 0% to 100% can be set in 1%
steps. The value 0% means travel up completely; the value 100% means travel down
completely.
12.9.7 Extended parameter – Value for slat position down (%)
Options
0..100%
Note: This parameter is only visible if the “Function switchover shutter/ roller
blind” parameters is set on shutter
The position that a connected blind slat is to be opened to is set via this parameter. The
associated 1-byte "Adjust" communication object must hereby be connected with a 1-byte
