52
12.13.4 Extended Parameter – Sending of objects
Options For change of value
For operation
The parameter "Sending of objects" specifies whether the object values for every button
operation are sent out or only if the object values have changed since the last sending
out.
12.13.5 Extended Parameter –Object values
Options Normal
Inverse
The object values can be sent "normal" or "inverse" via their associated 1-bit
communication objects. If the parameter "Object values" is set to "inverse" then all 1-bit
communication objects of the individual levels, send out their values inverted.
12.13.6 Extended Parameter – Bit pattern of object values
Options x of n
1 of n
12.13.7 The levels can be switch in two different bit patterns:
x of n (for 5 objects, object 0 to 4)
1 of n (for 5 objects, object 0 to 4)
00000
10000
11000
11100
11110
11111
00000
10000
11000
11100
11110
11111
12.13.8 Objects no
Object name Data type Flags
Switching stage 1
1 Bit DPT 1.001
C, W,
T
Switching stage 2 1 Bit DPT 1.001 C, W, T
Switching stage 3
1 Bit DPT 1.001
C, W,
T
Switching stage 4 1 Bit DPT 1.001 C, W, T
Switching stage 5
1 Bit DPT 1.001
C, W,
T
