ABB IRB 1010 User Manual

DescriptionSymbol
See user documentation
xx0900000813
Read user documentation for details.
Which manual to read is defined by the symbol:
• No text: Product manual.
Before disassembly, see product manual
xx0900000816
Do not disassemble
xx0900000815
Disassembling this part can cause injury.
Extended rotation
xx0900000814
This axis has extended rotation (working area) compared to
standard.
Brake release
xx0900000808
Pressing this button will release the brakes. This means that
the robot arm can fall down.
Continues on next page
20 Product manual - IRB 1010
3HAC081964-001 Revision: B
© Copyright 2022 ABB. All rights reserved.
1 Safety
1.2.2 Safety symbols on manipulator labels
Continued
