ABB IRB 1600 - 5/1,2 type A User Manual

2 Installation and commissioning
2.5.2. Robot cabling and connection points
833HAC026660-001 Revision: C
© Copyright 2006-2008 ABB. All rights reserved.
Customer cables (option)
The customer cables specified below are connected between robot and controller.
The customer cables are ordered according to current protection class of the robot.
Customer cables for robots with standard protection
Customer cables for robots with foundry and wash protection
Cable (standard) Art. no.
Connection
point, robot
Customer cable, power-signal, 7 m 3HAC3353-1 R1.CP/CS
Customer cable, power-signal, 15 m 3HAC3354-1 R1.CP/CS
Customer cable, power-signal, 22 m 3HAC3355-1 R1.CP/CS
Customer cable, power-signal, 30 m 3HAC3356-1 R1.CP/CS
Cable (foundry and wash) Art. no.
Connection
point, robot
Customer cable, power-signal, 7 m 3HAC8183-1 R1.CP/CS
Customer cable, power-signal, 15 m 3HAC8183-2 R1.CP/CS
Customer cable, power-signal, 22 m 3HAC8183-3 R1.CP/CS
Customer cable, power-signal, 30 m 3HAC8183-4 R1.CP/CS
Continued
