Position Transmitter Mounting Option
Example Installation: LMT200 Valve Position Transmitter and Hydraulic Control Valve
Close-up of Magnet Assembly
Valve
Transmitter
Actuator
Magnet
Assembly
Example Installation: LMT200 Valve Position TRansmitter and Hydraulic Control Valve
Valve
Stem
Bracket
Magnet
Mounting
Brackets
