ABB LMT Series User Manual

LMT100 AND LMT200 | MAGNETOSTRICTIVE LEVEL TRANSMITTERS | FF OI/LMT100/200/FF-EN REV. A
9
3 Transmitter overview
Transmitter components overview
The following represents an exploded view of the components
comprising the LMT Series level transmitter (see Figure 3).
Figure 3 Exploded view of LMT Series transmitter
 TopWorks Window Cover
 HMI Display Assembly
 HMI Connector
 Communication Board
 TopWorks Housing
 Terminal Board
 TopWorks Blind Cover
 Agency Approved Plug
 Plastic Plug
 Sensor Elbow Housing
 Sensor Tube
 
Note: Spare parts list in located in the back of chapter 10.
