AUTOMATIC CONTROL UNIT, OMD800
Rated Voltage
Rated Voltage is the rated voltage of the system. Value is announced as main voltage/phase voltage,
Volts. Factory setting is 400/230 V.
Figure 7.10 Rated Voltage, factory setting is 400/230 V
Rated Frequency
Rated Frequency means assigned frequency of the system. Value is announced as Hertz.
Factory setting is 50 Hz.
Figure 7.11 Rated Frequency, factory setting is 50 Hz
Number of Phases LN1
In Line 1 user can choose between a one-phase and a three-phase system with or without N. Three-
phase system with N is the default.
Figure 7.12 Number of phase LN1, 3 phases with N is the default
Number of Phases LN2
In Line 2 user can choose between a one-phase and a three-phase system with or without N. Three-
phase system with N is the default.
Figure 7.13 Number of phases LN2, 3 phases with N is the default
Rated Voltage
KA00260
400/230 V
Cancel EditOK
Rated Frequency
KA00261
50 Hz
Cancel EditOK
